SF COMPACT 300 24W/4000K IK10 IP65 LEDV

SF COMPACT 300 24W/4000K IK10 IP65 LEDV

OBLAST POUŽITÍ
- Koridory
- Schodiště
- Koupelny
- Veřejné prostory

VÝHODY PRODUKTU
- Tenký profil
- Odolnost proti vandalismu
- Vysoká svítivost
- Velmi homogenní světlo
- LED chráněna pro bezpečnou instalaci

VLASTNOSTI PRODUKTU
- Úhel nosníku: 120 °
- Typ ochrany: IP65
- Odolnost proti nárazu: IK10
- Pouzdro a kryt z polykarbonátu
- Test žhavého drátu podle IEC 60695-2-12: 850 ° C
- Možné propojení

TECHNICAL DATA
Electrical data
Operating mode Electronic control gear (ECG)
Nominal wattage 24.00 W
Nominal voltage 220…240 V
Mains frequency 50/60 Hz
Power factor ? ?0.90
Photometrical data
Color temperature 4000 K
Luminous flux 1920 lm
Light color (designation) Cool White
Color rendering index Ra >80
Luminous efficacy 80 lm/W
Light technical data
Beam angle 120 °

Diameter 300.0 mm
Height 61.0 mm
Colors & materials
Body material Polycarbonate (PC)
Housing color White
Product color White
Temperatures & operating conditions
Ambient temperature range -20…50 °C

Additional product data
Product remark Available from December 2017
Mounting location Ceiling / Wall
Capabilities
Dimmable No
Type of connection Fixed connection (terminal)
LED module replaceable Not replaceable
Certificates & standards
Luminous efficacy of lamp in luminaire 80 lm/W
Protection class II
Type of protection IP65
Standards CE/CB/TÜV SÜD
Protection class IK (shock resistance) IK10
Photobiological safety group RG 0
