8" Windows Rugged Tablet with Intel® Celeron® N6211

Vlastnosti:
Intel Celeron N6211 Elkart Lake Processor rugged tablet PC
8” 1280x 800 IPS LED panel s direct optical bonding
Optional expansion port DB15 connector
Sunlight readable with antiglare solution
Projected capacitive (PCAP) multitouch
USB 3.0 A, USB 3.0 C connectors
IP65 waterproof and dustproof

Display
Type Projected Capacitive Multi Touch
Bonding Optical Bonding pre Sunlight Viewability
Resolution 1280x800
Size 8.0 inches
Contrast Ratio 1500:1
Panel Brightness 800.0 nits
View Angles 80,80,80,80

System Specification
Procesor
Intel Celeron N6211 1.2 GHz (turbo boost up to 2.60 GHz)
Intel Pentium N6415 1.2 GHz (turbo boost up to 3.00 GHz) (Optional)

Memory 4GB LPDDR4
8GB LPDDR4 (Optional)

Storage 128GB SSD
Additional storage available with micro SDXC card slot
256GB SSD (Optional)
512GB SSD (Optional)

Security Trusted Platform Module (TPM) 2.0

Operating System Windows 10 IoT Enterprise LTSC (64 bit)
Windows 11 IoT Enterprise SAC (64 bit) (Optional)
WLAN Support

BT Support
WWAN 4G LTE (Optional), 5G (Optional)
GNSS GPS, GLONASS
RFID Mutually Exclusive with Barcode Reader
HF RFID Reader 13.56 MHz (Optional)
LF RFID Reader 125 KHz (Optional)
Sensors Light sensor/ Gsensor/ Gyro
Smart Card Reader Smart Card Reader Kompletný s ISO78161.2.3 T=1 a T=O protokol (Optional)

Camera
Front Camera 2MP Front Camera
Rear Camera 8MP Rear Camera with Autofocus and LED Light

Mechanical
Dimension 225 x 148 x 20.5 mm (10 x 7.76 x 0.8 inches)
Weight 0.9 kg with battery
Cooling System Fanless design

IO Ports
USB Port 1 x USB 3.0 (Type A), 1 x USB 3.0 (Type C)
SD Card Slot 1 x Micro SDXC Slot
SIM karta Slot 1 x Micro SIM karta slot
Audio 1 x Audio combo 3.5 mm audio combo jack
Dual Digital Mic With Noise Cancellation
Dual Speaker
Expansion Port 1 x 15pin Dsub connector
Indicator 4x LED Indicator pre Power, Battery, HDD, RF status
Docking Connector 1 x 19pin docking connector

Environment
Operating Humidity 10% až 90% RH, noncondensing
Operating Temperature -20°C až 60°C
StorageTemperature -30°C až 70°C (-22°F až 158°F)
Shock MILSTD810H Method 516.8 Procedure I
Vibration MILSTD810H Method 514.8 Procedure I
IP rating IP65
Drop MILSTD810H Method 516.8, 5 ft

Certification
Certification CE, FCC
Security Function
SOTI MobiControl SOTI MobiControl Compliance
Kensington Lock Kensington Lock Support

Control
Button 1 x Power, 1 x menu,
3 x Programmable Function Keys

Power
Battery 7.6V, typ. 4200 mAh Li Polymér Battery (2S2P)
Battery Operating Time Standard. Battery: 6 hours
Power Rating 19V DC Adapter 100-240V, 50-60Hz / 19V DC

Accessory
Accessory
Adapter and Power Cord
Štandard Battery Pack

Optional Accessory
Desk Dock (Optional)
Vehicle Dock (Optional)
USB-A Cable (Optional)
Battery Charger (Optional)
Vehicle Charger (Optional)
Hand Strap (Optional)
Vehicle Cradle (Optional)
LAN Cable (Optional)
Capacitive Stylus (Optional)

Barcode Scanner
Barcode Scanner 1D/2D barcode reader (Optional)
