- Winmau M116P - 11.6 \"FullHD odolný tablet, Intel Pentium N4200, 4GB / 128GB, IP65, Windows 10 IoT M116P
Winmau M116P - 11.6 "FullHD odolný tablet, Intel Pentium N4200, 4GB / 128GB, IP65, Windows 10 IoT M116P
Špecifikácia: 11.6 ", FullHD 1920x1080, Projekčne kapacitné touchscreen, Intel® Apollo Lake Pentium N4200 Processor, 4GB RAM, 128GB SSD, Full IP65, -20 ° C ~ 60 ° C, 19V DC, Windows 10 IoT Enterprise• Intel® Pentium® N4200 1.1GHz (Turbo up to 2.5 GHz)
• 11.6 "1920 x 1080 LED panel with direct optical bonding
• IP65 water and dust proof with MIL-STD-810G Rugged housing
• Optional Integrated 1D / 2D Barcode Reader and HF RFID for data collection
• Removable battery with hot-swap function for all day productivity
• 802.11ac WiFi, BT 5.0, 4G LTE, GPS Wireless Connectivity
• Optional GigaLAN Port
The M116 platform is a next-generation Windows Rugged tabliet series designed to boost efficiency in
a mobile, versatile form factor. The large 11.6-inch sunlight Readable full HD display allows for a
premium viewing experience no matter where work takes place. The M116P allows for efficient
performance with Intel Pentium processing with all day use with a hot-swappable battery dizajn.
Multiple wireless connectivity options and data capture modules allows users to complete their tasks
reliable; from warehouses, to vehicle mounted, to field service external use. All these tools suited for
productivity encased in an IP65 water and dust proof Rugged housing with MIL-STD 810G specs
ensures that the M116P is the ultimate Rugged tabliet designed with mobile productivity in mind.
Display Specifications
Size 11.6-inch display with LED Backlight
Resolution 1920 x 1080 Full HD
Contrast Ratio 1000: 1
Panel Brightness 850 nits with direct optical bonding for sunlight readability
Viewing Angle 89/89/89/89
Touch Projected Capacitive multi-touch
Technology • Anti-glare technology (Default)
• Automatic screen rotation
System Specification
CPU Intel® Pentium® N4200 1.1GHz (Turbo up to 2.5 GHz)
System Memory 4GB LPDDR4 RAM 1 (up to 8GB)
Storage 128GB SSD (options up to 512GB)
Additional storage available with micro SDXC card slot
Graphics Intel® HD Graphics 504
Operating System Windows 10 IoT Enterprise (64 bit)
Sensors Light sensor / g-sensor / Gyro / E-compass
wireless Communication
WLAN 802.11 a / b / g / n / ac WiFi
Bluetooth Bluetooth 5.0
GNSS GPS, GLONASS
WWAN Optional 4G LTE
interface
Docking Connector 1 x 19-pin docking connector
HDMI 1 x micro HDMI
USB 1 x USB 3.0 (Type A), 1 x USB 3.0 (Type C) 2
Power Input 1 x Power Jack
Micro SD 1 x micro SDXC slot
Audio 1 x Audio combo connector (Mic in or Line Out)
LAN 1 x RJ45-10 / 100/1000 GigaLAN port (Optional)
Expansion Port 1 x Expansion connector for USB 2.0 / Full RS232 (Optional)
Micro SIM 1 x Micro SIM card slot
mini PCIe 1 x Mini PCIe for WWAN Module
Keyboard and Input
Physical Buttons 1 x Power; 3 x function keys
Touch 10-point multi-touch, supports Rain / Glove / Stylus Modes
audio
Microphone Built-in dual digital mic with noise cancellation
Speaker 2 x 1 watt front-facing speakers
Cameras
Front Camera 2MP front camera
Rear Camera 8MP rear camera with autofocus and LED light
data Capture
Integrated Optional 1D / 2D Barcode Reader
Optional HF RFID reader 13.56 MHz
Optional Smart Card Reader
Add-on Module Optional add-on UHF RFID Reader or Smart Card Reader
Security Function
Security • Trusted Platform Module (TPM) 2.0
• Kensington Lock
Mobile Device Mgmt. SOTI Mobicontrol compatible
Certificate
• CE, FCC
Mechanical and Environment
Dimensions (W x L x H) 300.67 x 201.97 x 22.5 mm
Weight 1.35 kg
Operating Temperature -20 ° C to 60 ° C (AC mode), -10 ° C to 50 ° C (Battery mode)
Storage Temperature -30 ° C to 70 ° C
Operating Humidity 10% to 90% RH, non-condensing
Shock MIL-STD-810G Method 516.6 Procedure I
Vibration MIL-STD-810G Method 514.6 Procedure I
Drop MIL-STD-810G Method 516.6, 4 ft to concrete
IP Rating IP65 certified, dustproof and waterproof
Power Management
Power Input 19V DC
AC Adapter 100-240V, 50-60Hz (19V DC)
Battery Hot-swappable 7.7V typ. 5900 mAh Li-Polymer Battery (2S1P)
Optional 7.4V typ. 10280 mAh Li-Polymer Battery (2S2P)
Battery Operating Time Std. Battery: 8 hours
Standard Accessories
• Adapter and Power Cord
• Capacitive Stylus
• Standard Battery
optional Accessories
• Desk Dock
• Vehicle Dock
• Vehicle Charger
• Battery Charger
• Smart Card Reader
• UHF RFID Reader
• High Capacity Battery
• Hand Strap
• VESA Mount Kit
• Shoulder Strap
• Carry Bag
• Micro HDMI Cable
• USB-C to Ethernet Adapter
• USB-C to RS232 Adapter
• USB-C to USB-A Hub
* Obrázky sú len ilustračné!
* Položky označené ako "OPTIONAL" nie sú súčasťou tejto konfigurácie a je nutné si ich prípadne vopred u predajcu do konfigurácie pridať.
* Ak nie je uvedené inak, je dodávané s operačným systémom Windows 10 IoT v multijazyčné lokalizácii (vrátane češtiny).
Parametre
Doplňujúce informácie
| Farba tabletu | černá |
|---|
